The open design of Sukup Ag and Industrial Buildings allows you to adapt the space to your specific needs. Need room to fold out your planter to check the row units? Want to add an office? Or a bay for your combine? You can have it with a Sukup Building.

Framework

  • Sukup’s sturdy, rigid frame structure allows plenty of open area to house your machinery
  • I-Beam structural steel used in corners and end wall columns for additional strength
  • Clear span for large open areas
  • Multi-span construction available to reduce cost
  • Structural framing standard in gray oxide primer, red optional
  • Pre-punched purlins and girts ensure a proper fit
  • Pre-punching also speeds installation for lower construction costs
  • Purlins and girts are galvanized for long life
  • Framed openings for standard and oversized doors

Wall Panels

  • Sukup wall and roof panels are made from Galvalume®+ AZ-55 substrate for extreme corrosion resistance
  • Twelve exterior and trim colors to choose from

Exterior Wall Panels

  • 26 gauge
  • 36” coverage
  • 1-1/4” rib height
  • 12” on center
  • 50 grade

Interior Liner Panel Features

  • 29 gauge
  • 36” coverage
  • ¾” rib height
  • 6” on center
  • 50 grade Galvalume®+

Roof Panels

Standing Seam Roof

  • The seams on Sukup standing seam roofs are mechanically-rolled in the field to create a 360˚ Pittsburgh double-lock seam
  • Creates a tight, durable, virtually leak-proof seal
  • Movable roof clips allow the roof sheets to expand and contract with temperature changes
  • Allowing for expansion and contraction prevents stress on the roof components that could make the roof more prone to leaks and wind damage

Screw-Down Roof

  • This style of roof is economical and simple to install
  • 26 gauge
  • 36" coverage
  • 1-1/2" rib height
  • 12" on center
  • 50 grade Galvalume+

Product Accessories

  • Wide selection of steel-framed, easy-to-install doors and windows
  • Wainscot wall panels to accent the outside of your building
  • Interior partition walls to section off your building
  • Commercial grade fiberglass insulation systems (up to R-45 in the roof!)
  • Eave and gable extensions and canopies
  • Gutters (Northern and Southern) and downspouts
  • Complete trim packages in all of Sukup's standard colors
Product Features
  • Customizable
  • Clear Span Construction
  • Standing Seam or Screw-Down Roof
  • All Sheeting Available in Galvalume® + and All Standard Colors
